Structural Engineering — Duluth, Georgia

Structural design, assessment, and construction-phase support for residential and commercial buildings.

Scope of services
Licensed Professional Engineer Multi-state practice NCEES Record
T.O. PLATE T.O. SUBFLOOR GRADE T.O. FOOTING ROOF SHEATHING & RAFTERS (2) TOP PLATES, LAP SPLICE STUD WALL @ 16" O.C., TYP. FLOOR FRAMING — SEE PLAN SILL PL. W/ ANCHOR BOLTS FOUNDATION WALL CONT. FOOTING, SIZE PER PLAN UNDISTURBED SOIL A S-1.0 TYPICAL WALL SECTION SCALE: 3/4" = 1'-0"
Sheet S-1.0 — Cover Germany Engineering, LLC
S-1.1Sheet index
SheetTitleStatus
S-1.0CoverIssued S-2.0Scope of ServicesIssued S-3.0The FirmIssued
AMatch line — cont'd on sheet S-2.0
S-2.1Scope of services

Scope of services

Scope of Services
  1. Structural design
  2. Structural assessments and code-compliance evaluations
  3. Independent third-party structural review
  4. Construction-phase support and plan-review comment responses
S-2.2Typical details

Typical details

COLUMN BASE PL. ANCHORRODS CONT. REINF.SEE SCHED. W — PER PLAN, CTR. ON PIER
1 / S-2.2 · Spread footingN.T.S.
1/4 TYP. W-SHAPECOLUMN BEAMSEE PLAN SHEAR TABW/ (3) BOLTS
2 / S-2.2 · Beam to columnN.T.S.
SHEATHING W/EDGE NAILING HOLD-DOWN,SEE PLAN SILL PLATE ANCHOR ROD W/PLATE WASHER
3 / S-2.2 · Shear wall hold-downN.T.S.
BMatch line — cont'd on sheet S-3.0
S-3.1Firm profile

The Firm

Principal

Rob Germany, PE

  • LicensureMulti-state practice
  • RecordNCEES Record
  • Based inDuluth, Georgia
